Hubei Xindongri Special Vehicle Co., Ltd.

XDR 4000Liters New Fire Truck

  • Category:Water tank fire truck
  • Views:18
  • Brand XDR
  • Product origin Hubei,China
  • Delivery time within 30 days
  • Brand XDR
  • Product Manual:1.Common, middle and high level fire fighting truck products for different countries and regions; 2.Dongfeng, ISUZU, HOWO,JAC,JMC,FOTON chassis for option to meet different requests; 3.Different c
BASIC INFO Inquiry
XDR 4000Liters new fire truck
General Vehicle Brand XDR
Chassis Brand  Dongfeng
Overall Dimension 6840x2190x3010mm
GVW/Curb Weight 8395kg
Front/rear track 1745/1620mm
Approach/departure angle 21/13 (°)
Front/rear suspension 1130/1910
Leaf spring 8/10+7
Cab Cab Seat 5,6
Air Conditioner optional
Chassis Drive Type 4x2
Transmission Manual
Wheelbase 3800
Tyre Specification 7.50R16
Tyre No. 6+1
Max Speed 95km/h
Paint Red or as request
Engine Fuel Type diesel
Engie Model CY4102BZQ
Engine Brand  Dongfeng
Power 88kw/120hp
Displacement 3856cc
Emmission Standard Euro 3
Superstructure front and rear cupboard room, top mounted fire monitor,rear folding ladder, top  mounted alarm and siren
Others water flow                                                                                                                                                   30L/S
Pump PS30
Pressure 1.0Mpa
Fire distance 50m
Optional Colour for optional, LHD and RHD for optional,Air conditioner for optional
