1.Stainless Steel Water Tank Car technical parameter
|
10cbm high quality water sprinkler truck |
|||
|
Vehicle Parameters |
|||
|
General |
Vehicle Model |
YZR5180GSSDFH |
|
|
Vehicle Brand |
XDR |
||
|
Chassis Brand |
Dongfeng |
||
|
Overall Dimension(mm) |
8400×2500×3100 |
||
|
GVW/Curb Weight(kg) |
18000/6890 |
||
|
Chassis Parameters |
|||
|
Cab |
Cab Seat |
2,3 |
|
|
Air Conditioner |
Optional |
||
|
Engine |
Fuel Type |
diesel |
|
|
Engie Model |
ISB190 |
||
|
Engine Brand |
Dongfeng Cummins |
||
|
Power(hp) |
190 |
||
|
Displacement(cc) |
4500 |
||
|
Emmission Standard |
Euro4 |
||
|
Chassis |
Drive Type |
4*2 |
|
|
Transmission |
6 speed, Manual |
||
|
Wheelbase(mm) |
4500 |
||
|
Tyre Specification |
9.00R20 |
||
|
Tyre No.(pcs) |
6+1 |
||
|
Max Speed(km/h) |
98 |
||
|
Paint |
Blue and White |
||
|
Water Tank Structure Parameters |
|||
|
Tank Volume |
10000L |
Tank Material |
Carbon Steel |
|
Tank Thickness |
4/5/3.5mm |
Nozzle Sprinkling Width |
≥14m |
|
Range of water cannon |
≥28m |
Color and Logo |
Optional |
|
Standard configuration |
Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder. |
||
|
Selective configuration |
stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump, fire pump, fire gun,pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights |
||
|
Extended model |
water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck,and etc. |
||
2.foton 4000L Good Quality Japan Watering Cart charateristics
(1) The materail for water tanker is carbon steel Q235,which is very strong.
(2) Multipal Function:sprinkling, spraying, cooling, dusting and flushing dust on various roads;road maintenance, landscaping and emergency fire fighting, transportation and water diversion.
3.Working show
XDR water sprinkler truck can be adjusted for front flushing,rear watering,side spraying and so on.
4.Packing and transportation: Wax
(1) We spray wax to protect the truck before shipment.
(2) Waterproof cover and net can be provided for customer's optional choice.
(3) If only superstructure body which loaded in container,suitable strong steel support is provided.
(4)Standard container,Frame container,Open container,Roro ship are regular sea way shipment way. Road transportation is for road way delivery.
5.Payment terms
-
T/T
-
L/C
6.Delivery time:Generally 25days
7.Our advantages
1.Having 15 years experience in special trucks
2.Good quality :based on the standard of international request.
3.Competitive price:more reasonable than most suppliers
4.On-line delivery time:shipment as contract once we confirm
8.FAQ
1.Q:Trading or Factory? Location ?
A: Hubei Xindongri Special Purpose Vehicle Co., Ltd., is one of the most professional manufacturers for special purpose vehciles located in Suizhou City, Hubei Province, China. Our factory covers nearly 80,000 square meters, with own office builing, canteen, workshop, tesing square,etc.
2.Q:Visit ?
A:You will be welcomed here for factory inspection,you could take Plane to the capital city Wuhan Tianhe airport, and we will pick up you from the airport to our wuhan office to have a first visit and communication.Then we will go to Our suizhou headquarters together.
3.Q: Workshop?
A:We have experienced engineer and skillful workers here for your service.
4. Q: Delivery time & Stock & Payment ?
A:Please contact us for checking the instant Production arrangment and Stock condition here.Normally 25days.
Packing: waxed, by RORO ship, or Bulk ship
Payment: T/T be prefered, deposit first and balance paid before the delivery from factory.
